MBR308 DMR Rifle Replica
- Material: Metal + polymer
- Length: 930 - 1030 mm
- Weight: 3190 g
- Color: Black
- Muzzle Velocity: ~500 FPS
- Engine: Electric
- Manufacturer: Umbrella Armory / G&G Armament
MBR308 DMR
Rifle Replica
Do you want a
modified replica but tuning is a dark art for you? Umbrella Armory has
you covered! Replicas sold by this brand are upgraded models of carbines from
known manufacturers such as G&G or Krytac.
Internal elements of stock replicas are replaced with high quality,
appropriately-selected parts by known brands. Thanks to this, you get a
perfected, ideally put together and tested inside and out replica ready for
action straight out of the box.
MBR308 is a
highest-quality and class replica made by a known and renowned G&G company.
Due to the materials used and technologies implemented, the replica is intended
for most demanding Users that value realism and quality.
List of parts
installed in Umbrella Armory workshop:
Gearbox: reinforced gearbox G2
Gear Set: 20:1 SiegeTek SSG
Motor: G&G Ifirit 25,000 RPM Motor
(Long Type)
MOSFET: G2 Trigger ETU 2.0 + Perun ETU ++
Bearings: Umbrella Armory 8 mm Steel Ball
Main Spring: ASG (M135)
Piston Head: Lonex POM AOEd
Piston: Rocket, 15 steel teeth
Trigger: modified, red G&G
Tappet Plate: modified TO 8.96 mm
Tappet Spring: G&G Tappet Spring
Cylinder: 1/1
Cylinder Head: modified Modify with a double O-ring
Nozzle: VFC POM with O-ring
Hop-Up Chamber: G&G Rotary + Umbrella Armory 3D R-Hop arm
Hop-Up bucking: green G&G
Internal Barrel: steel Umbrella R-Hop Prometheus Tight Bore 6.03
mm (460 mm)
The set
includes:
- replica
- G&G G2 magazine
= 11.1 battery (1300 mAh)
- Perun ETU++ diagnostics card
- User’s manual
- Umbrella Armory certificate
NiCd
rechargeable battery is characterized by high efficiency
current-carrying capacity, but there are disruptive effect on memory.
Should be unloaded and loaded in the full cycle, ie, it is recommended
to fully discharge, and after unloading must charge the battery
immediately without leaving it for a long time in a discharged state.
NiMH batteries have a higher self-discharge over time and shorten the
life - on the other hand, they earn about 30% more capacity.
Blow back is a simulation system of the cocking lever - it imitates the work of it as the equivalent sharp. This system raises the realism and adds a lot more experience during shooting.
It is the spped of bb, while its leaving the innerbarrel of replica. This speed is measured in FPS (Feet Per Second).
1 FPS = 0,3 m/s
1 J = 99 m/s
1 J = 326,7 FPS
Indications v2, v3, v6 does not mean the level of advance, but only shape of gearbox skeleton which was used and selected by the manufacturer depending on the capabilities of the body of the replica. For example, a models of the M4/M16 family, MP5, have a v2 gearbox, while the AK family have gearbox v3.
Hop-Up system is used for overclocking bb during the shot (putting it in rotation), through which, it extends its flight path. Acting laws of physics make that bb lift up, while the gravitational force take it down. Appropriate adjustment of Hop-Up, will compensate for these two factors, which result in long and straight flight for longer distance and be greater focus shot (to improve accuracy).
